3D Design Brief

I need a 3d design that will be ready for printing. I have included a rough 3d draft that needs refining and more detail before being printed. The current design is missing the cam clamp component and accurate measurements. Each round portion needs to include the cam mechanisms. The internal width of the oval needs to be 3/4 of an inch, the width of the face of the oval needs to be 1/8 and the distance between the front piece and back needs to be 3/16 of an inch. the depth of the oval piece needs to be 1/16

Industry/Entity Type

Printing

---

Files

Download all files - 0.1 MB
